Quantity: 0 Pieces |
Size: DN65 |
Pressure: 1.0 MPa |
Body Material: Cast Tin Bronze, Cast Silicon Brass |
Type: AS |
Applicable Medium: Sea Water, Fresh Water
Materials of Main Parts:
(1). Body: Cast Tin Bronze, Cast Silicon Brass;
(2). Cover: Cast Tin Bronze, Cast Silicon Brass;
(3). Disc: Cast Tin Bronze, Cast Silicon Brass;
(4). Stem: Aluminum Bronze;
(5). Seal Face: Cast Tin Bronze, Cast Silicon Brass
3. Dimensions
DN (mm) | L | L1 | H | L2 | H1 | t | D | D1 | D2 | b | dₒ | n | Th. | Dₒ | S | m | kg |
65 | 284 | 100 | 220 | 110 | 90 | 6 | 185 | 145 | 122 | 17 | 18 | 4 | M16 | 140 | 12 | 20 | 10.70 |
4. Drawing
