CBT422-1993 Fluid Watching Machine

CBT422-1993 Fluid Watching Machine

Quantity: 0 Pieces
Size: DN40
Pressure: 0.4 MPa
Body Material: Cast Iron
Type: T and TS
  1. Available Medium: Water, Oil

  2. High amount of use temperature 70 degree

  3. Materials of main Parts

(1). Body: Cast Iron;

(2). Transparent Pipe: Plexiglass;

(3). Transparent Board: Ordinary Glass;

(4). Cover: Cast Tin Bronze;

(5). Cover Board: Carbon Steel

    4. Dimensions

Mpa

DN

d1

H

t

D

D1

D2

d

b

n

Th

kg

0.4

40

40

160

8

125

93

74

15

16

6

M4

5.6
