| Quantity: 0 Pieces |
| Size: DN25 |
| Pressure: 0.5 MPa |
| Body Material: Cast Tin Bronze |
| Type: AJ |
Available medium: Water and Oil
Materials of main Parts
(1). Cock Body: Cast Tin Bronze;
(2). Handle: High-qualite Carbon Steel;
(3). Filling Gland: Cast Tin Bronze;
(4). Filling Seat: Cast Tin Bronze
3. Dimensions
DN | L | H | H1 | t | D | D1 | dₒ | b | n | Th | L0 | kg |
25 | 130 | 105 | 41 | 5 | 95 | 75 | 12 | 10 | 4 | M10 | 160 | 3.1 |
