CBT4017 J kind of flange Bronze 1.6MPa check valve
  • CBT4017 J kind of flange Bronze 1.6MPa check valve
CBT4017 J kind of flange Bronze 1.6MPa check valve

CBT4017 J kind of flange Bronze 1.6MPa check valve

Quantity: 0 Pieces
Size: DN15
Pressure: 1.6 MPa
Body Material: Cast Tin Bronze
Type: BJ

Available Medium: Air and other Gas, Oil pulsation Water.

DN: 15 ~ 40mm

Materials:

(1). Body: Cast Tin Bronze;

(2). Disc: Cast Tin Bronze;

(3). Guides the pole: Cast Tin Bronze;

(4). Coat Nut: Cast Tin Bronze;

Dimensions

DN

L

H

t

D

D1

b

d0

n

Th

m

kg

15

70

56

4

95

70

12

15

4

M12

5

2.36

 CBT4017 J kind of flange Bronze 1.6MPa check valve.jpgCBT4017 J kind of flange Bronze 1.6MPa check valve1.jpg
