JIS F7311 - JIS 5K Cast Steel Globe Valve

1.  The flanges shall conform to nominal pressure 5K of JIS B 2210

2. The name plate shall be specified by purchaser as required

3. Series F7311

4. kg: 309


5. Materials:

(1). Body: Cast Steel;

(2). Bonnet: Cast Steel;

(3). Hand wheel: Cast Iron;

(4). Disc: Bronze/Stainless Steel;

(5). Body  Seat: Bronze/Stainless Steel;

(6). Disc Gland: Bronze/Stainless Steel;

(7). Stem: Bronze/Stainless Steel;

(8). Washer : Alloy Tool Steel;

(9). Bush: Bronze;

(10). Packing Ring: Bronze/Stainless Steel;

(11). Packing Gland: Branze;

(12). Bonnet Bolt: Rolled Steel;

(13). Packing Glang Bolt: Rolled Steel;

(14). Bonnet Nut: Rolled Steel;

(15). Packing Gland Nut: Rolled Steel;

(16). Handle Nut: Brass;

(17). Set Screw:Rolled Steel;

(18). Split Pin: Brass Wire;

(19). Disc Stopper: Brass Plate/Stainless Steel;

(20). Packing: Asbestos;

(21). Gasket: Asbestos;

(22). Name Plate: Brass Plate

    4. Dimensions
