Quantity: 0 Pieces |
Size: 100 |
Pressure: 5K |
Body Material: Cast Iron |
Type: S |
Materials of main Parts:
(1). Boby: Cast Iron;
(2). Cover: Cast Iron;
(3). Strainer Cylinder: Steel / Stainless Steel;
(4). Strainer Handle: Steel / Stainless Steel;
(5). Cover Pusher: Ductile Iron / Steel;
(6). Pushing Bolt: Steel / Brass;
(7). Plug: Brass;
(8). Handle of Cover: Steel;
(9). Set Screw: Steel / Stainless Steel;
(10). Gasket: Rubber
2. Dimensions
F7121 | Size | d | D | C | N-h | t | L | L1 | H | kg |
5K | 100 | 100 | 210 | 175 | 8-19 | 20 | 320 | 160 | 400 | 37.5 |
