| Hose dia.: 600mm |
| Length: 1000mm-3000mm |
| Wall thickness: 40-45 mm |
| Working temperature: -20 ~ +50 |
DN600 Dredge Suction Hose
Technical parameter
Hose dia.: 600mm
Length: 1000mm-3000mm
Wall thickness: 40-45 mm
Working temperature: -20℃ to +50℃
DN(mm) | Flange OD(mm) | Flange thickness(mm) | Bolt hole | Length(mm) | Wall thickness(mm) | ||
P.C.D.(mm) | No. | Hole dia.(mm) | |||||
600±5 | 790±3 | 45±2 | 740±1 | 20 | 27±1 | 1000-3000 | 40-45 |
NOTE:The specifications for reference,the dredge suction hoses can be customized according to client’s requests.
Drawing of DN600 Dredge Suction Hose
