| Quantity: 0 Pieces |
| Size: DN20 |
| Pressure: 2.5 MPa |
| Body Material: Cast Steel |
| Type: A and AS |
Available medium: The temperature is not lower than -165 degree liquefied gas, Corrosive medium.
DN: 65 ~ 100mm
PN: 1.0 ~ 2.5MPa
Materials of main Parts:
(1). Body: Cast Steel;
(2). Cover: Cast Steel;
(3). Disc: Cast Steel;
(4). Fastener: Stainless steel
5. Dimensions
DN | L | H | t | D | D1 | D2 | dₒ | b | n | Th | m | kg |
20 | 150 | 84 | 6 | 90 | 68 | 48 | 13 | 11 | 4 | M12 | 6 | 2.6 |
