2×50kN Hydraulic Ramp Winch

2×50kN Hydraulic Ramp Winch

Main Technical Parameters

1. Working load: 50 kN (single drum operation)

                 100kN (double drum operation)

2. Support load: 150 kN (single drum operation)

                 200 kN (double drum operation)

3. Speed: ≥9 m/min (1st layer)

4. Steel wire dia.: φ24mm

5. Capacity: 250 m (7th layers, single drum operation)

             500m (7th layers, double drum operation)

6. System pressure: ～16Mpa

7. System flow:  ～100 L/min (double drum operation)

8. Safety value regulating pressure: 24Mpa

9. Driving Type: Hydraulic

10. Hydraulic transmission device:

            Displacement:2975ml/r

            Torque: 8398 N.m

11. Electric Motor:

            Model: Y160L-4-H (2 SETS)

            Power: 2×15 kW

            Speed: 1476 r/min

            Duty: 415V/50HZ

Drawing of 2×50kN Hydraulic Ramp Winch

Finished Image of 2×50kN Hydraulic Ramp Winch
